IOGear GCS1644 - GCS1644 Overview

GCS1644
Dual Link Dual View
DVI KVMP SWITCH
8
GCS1644 Overview
Front View
2 43 5 6 7
1
1. Port 1 Pushbutton
2. Port 2 Pushbutton
3. Mode Button
4. Port 3 Pushbutton
5. Port 4 Pushbutton
6. Front Panel Console Mic. Connection
7. Front Panel Console Audio connection
8. Front Panel USB 2.0 Peripheral Sharing Port
8
