IOGear GCS1902 - Product Features Overview

5
• 2 (GCS1902) or 4 (GCS1904)-Port DisplayPort KVMP Switch with USB 3.0 Hub
and audio
• One USB console controls two (GCS1902) or four (GCS1904) computers and two USB
3.0 peripherals
• Computer selection via front panel pushbuttons, hotkeys, and mouse
1
• Independent switching of KVM, USB, and Audio focus
• Superior 4K video quality – 3840x2160 @30Hz
• 2-Port USB 3.0 Hub with SuperSpeed 5Gbps transfer rate
• DisplayPort 1.1 compliant, HDCP compliant
• Supports HD audio through DisplayPort
2
• Full bass response for high quality 2.1 channel surround sound systems
• Power On Detection – if a computer is powered OFF, GCS1902/1904 automatically
switches to the next powered ON computer
• Dual-Mode DisplayPort (DP++) supports HDMI and DVI output with an adapter
3
• Hot pluggable – add or remove computers without turning GCS1902/1904 power OFF
• Mouse emulation or bypass feature supports most mouse drivers and multifunction mice
• Multi-platform support –Windows
®
7, Windows
®
8.1, Windows
®
10, Mac
®
, and Linux
®
• Multilingual keyboard mapping supports English, Japanese, French, and
German keyboards
• Mac
®
keyboard support and emulation
4
• Auto Scan Mode feature to monitor all computers
• Firmware upgradeable
Note:
1. Mouse port switching supported by mouse emulation mode using a USB 3-button
mouse wheel.
2. HD audio through DisplayPort cannot be switched independently.
3. Dual-Mode DisplayPort technology (DP++) does not require an active adapter for most
single display setups. Active DisplayPort adapters are recommended if you are unsure
of the video source’s DP++ compatibility.
4. PC keyboard combinations emulate Mac
®
keyboards. Mac
®
keyboards only work using
their own Operating System.
Features
