Visual Reference Guide

Figure 5. The Ioline StudioJet Front View.

D E

A. Left End Cover

B. Drive Shaft Marker

C. Pinchwheel Lever

D. Pinchwheel

E. Drive Shaft

F. Right End Cover

G. Keypad

H. Stand Leg

I. Inkjet Cartridge

J. Carriage

K. Stand Leveling Foot

L. Feed Shaft

M. Cross-member

N. Platen

O. Traverse

KEY
