Iomega ZIP drive 100 - Preparing Drive Bay Installation

Locate a vacant drive bay and remove the
panel cover.
3
1
/2-inch Bays
(You must first remove the
mounting sled. See Step 7a.)
5
1
/4-inch Bay
(Your Zip Insider ships ready to install
in a 5
1
/4-inch drive bay.)
3
1
/
2
-inch drive bays ONLY.
To install your Zip Insider in a 3
1
/
2
-inch drive bay remove the mounting
screws as illustrated and slide the drive out of the sled.
7a
7
4
