IOtech 640 and 650 927791 Specifications 11-1
Specifications – IOtech 640 & 650 11.a
Section 11.b, Specifications, Data Plots, contains a great deal of information in the form of plotted data. References
to the plots appear throughout this section [11.a], as applicable.
General Specifications
Environment:
Operating Temperature
640u and 650u: -40˚ to 60˚C
640e and 650e: 0˚ to 50˚C
Humidity: 0˚ to 95% RH, non-condensing
Vibration: IEC 60068-2-64
Shock: IEC 60068-2-27
Emissions: EN61326, 89/366EEC
Safety: EN61010
Ingress: IP 40
Power Consumption:
640e; 650e: 4.2W max
640u; 650u: 2.5W max
Input Power Range:
640e, 650e: 6.5 to 16 VDC
640u, 650u: 6.0 to 16 VDC
PC Communication:
640e; 650e: 10/100BaseT Ethernet
640u; 650u: USB2.0
Dimensions: 5.6” W x 7.1” D x 1.5”H
(142.2mm W x 180.3mm D x 38.1mm H)
Weight: 1.5 lbs. (675 g)
Warm-up: 10 minutes to rated specifications
Analog Specifications
Analog Measurements
ADC converter resolution: 24 bits
ADC converter type: Delta-sigma
Sample rates: up to 105,468 samples per second
Sample rate accuracy: ±50ppm
Channels:
640e; 640u: 4 input channels
650e; 650u: 5 input channels
Input connector: 1 BNC per channel
Input impedance from
640e / 640u
650e / 650u
High to ground
200kΩ || 130 pF
800kΩ || 120 pF
Low to ground
1kΩ
1kΩ
High to low
201kΩ
801kΩ
Input coupling: DC, AC, or AC + IEPE; software programmable per channel basis
