10. SETTING THE CONTROL PANEL BOARD 512 – 712 RIDER
i INFORMATION
If the control board is replaced, make sure the dip switches are set according to the type
of machine being used.
SW1 ( ON ) = 12 V machine power supply
SW2 ( ON ) = GEL batteries
SW3 ( ON ) = "RIDER" version
SW4 ( ON ) = Internal combustion engine
1
2
3
4
ON
