Introduction: 1
The MicroTimer is a complete electronic timer with two outputs which can be used to select general
functions for a set time, with a prior time setting and a post time setting.
Functions:
• Two control channels with fixed relays output
• Prior time setting 0-255 minutes
• Main setting 0-255 minutes
• Post time setting 0-255 minutes
• Service hours’ counter (cannot be reset)
• Service counter can be reset
• Power supply both for 24 volt as 230 volt
Specifications:
• Very strong plastic housing
• Suitable for internal or external installation
• Three keys: Start / Pause, Timer & Stop (internal and external)
• Bright green 2-digit LED display
Versions:
The MicroTimer is available in two different types, the difference between the two of them lies mainly in
the applied software:
Software –S: Three keys on the front
Rapid start function via Start / Pause key
Main time shortened with Stop key
-S, signal output
Software –P: Three keys on the front
Rapid start function via Start / Pause key
Main time shortened with Stop key
-P, pulse output
Software description:
(The software version is shown on the front plate of the MicroTimer, under the housing cover plates.)
- S software version
The timer can be started by pressing the Timer key. Before starting the main time, a prior time can be
selected, which is run before the main time. You can interrupt the main time by pressing the Start /
Pause key. If the Stop key is depressed, either the timer will stop operating or the post time will follow
automatically (depending on what has been previously set).
- P software version
This version is the same as the –S version, except for the control diagram. (See “Control Diagram”).
