Control diagram: 3
Operation in general
The timer starts with the pre-time. During the pre-time, the duration of the main-time will blink in the
display. The duration of the main-time can be limited during the pre-time by activating the Stop timer
button. The pre-time is programmable from 0 up to 255 minutes. The pre-time can be skipped by means
of the quick start function by activating the Start / Pause button. The main-time will follow automatically
after the pre-time. During the main-time the remaining time will appear on the display. The main-time is
programmable from 0 up to 2550 minutes.
The main-time can temporarily be interrupted by activating the Start / Pause button. The post-time will
follow automatically the main-time and is programmable from 0 up to 255 minutes. During the main-time
both relays are active, during the pre-time and the post-time, only relay 2 is active. During the post-time,
the message “CL” (cool) will appear in the display. The timer can be stopped by pushing the Stop
button. If the Stop button is activated during the main-time, the post-time will automatically be initiated.
When the Stop button is activated during the pre-time, the main-time will be shortened with 1 minute.
Relay control diagram:
–S software version,
(signal output)
–P software version
(pulse output)
Standard display
Timer Relay 1 Relay 2 Relay 1 Relay 2
Stand-by Off Off Off Off - (hyphen)
Prior time Off On Pulse Off Main time blinking.
Main time On On Off Off Remaining main time
Pause Off On Off Off Main time blinking.
Post time Off On Off Pulse CL
Prior time
Main time
Post time
Pause
- S software version
-
During the prior time, contact 2 is closed.
During the prior time, the display blinks with the
value of the main time.
-
During the main time, both contacts are closed
(relay 1 & 2). The display sh
ows the remaining
time. The Pause
key can be used for temporary
interruption of the main time.
-
During the post time, only contact 2 is closed.
During the post time the display shows "CL".
–P software version
- During the prior time, relay signals will no
t be
confirmed. During the prior time, the set value of
the main time will be displayed blinking.
-
When the main time begins, MicroTimer will
send a pulse to relay. The remaining time of the
main time will be shown on the display.
- When the post time be
gins, MicroTimer will
send a pulse to relay 2. The display will show
“CL”.
