C
HAPTER
13
| Security Measures
Access Control Lists
– 327 –
WEB INTERFACE
To add rules to a Standard IP ACL:
1. Click Security, ACL.
2. Select Configure ACL from the Step list.
3. Select Add Rule from the Action list.
4. Select IP Standard from the Type list.
5. Select the name of an ACL from the Name list.
6. Specify the action (i.e., Permit or Deny).
7. Select the address type (Any, Host, or IP).
8. If you select “Host,” enter a specific address. If you select “IP,” enter a
subnet address and the mask for an address range.
9. Click Apply.
Figure 175: Configuring a Standard IPv4 ACL
CONFIGURING AN
EXTENDED IPV4 ACL
Use the Security > ACL (Configure ACL - Add Rule - IP Extended) page to
configure an Extended IPv4 ACL.
CLI REFERENCES
◆ "permit, deny, redirect-to (Extended IPv4 ACL)" on page 726
◆ "show ip access-list" on page 730
