iPECS ES-3052GP - Table 16: Mapping Internal Per-Hop Behavior to Hardware Queues

C HAPTER 10 | Class of Service
Layer 2 Queue Settings
– 246 –
ES-3052 Series
CLI REFERENCES
◆ "qos map phb-queue" on page 887
COMMAND USAGE
◆ Egress packets are placed into the hardware queues according to the
mapping defined by this command.
◆ The default internal PHB to output queue mapping is shown below.
◆ The specified mapping applies to all interfaces.
PARAMETERS
These parameters are displayed in the web interface:
◆ PHB – Per-hop behavior, or the priority used for this router hop.
(Range: 0-7, where 7 is the highest priority)
◆ Queue – Output queue buffer. (Range: 0-3, where 3 is the highest CoS
priority queue)
6 Voice, less than 10 milliseconds latency and jitter
7Network Control
Table 16: Mapping Internal Per-hop Behavior to Hardware Queues
Per-hop Behavior 0 1 2 3 4 5 6 7
Hardware Queues 1 0 0 1 2 2 3 3
Table 15: CoS Priority Levels (Continued)
Priority Level Traffic Type
