HP Switch Software
Part Number: P21-010106, YLR-Series SLED 3.0
Published: April 2015
Revision: B
DCO: 956
Management and Configuration Guide
YLR-Series User Guide
and Configuration Guide

Table of Contents

Questions and Answers

  • W
    Wayne LamAug 19, 2025
    What to do if IPG Photonics Measuring Instruments show High Back Reflection error?
    • E
      Emily ByrdAug 20, 2025
      If the Measuring Instruments by IPG Photonics display a 'High Back Reflection' error, it means the back reflected power has exceeded the pre-installed maximal applicable level. First, check that the focus position is correctly adjusted and that there are no surfaces that could cause high back reflection. Then, reset the error using the RS-232 command (“RERR”) or the touch-screen display on the front panel.
  • C
    Cynthia CooperAug 21, 2025
    Why do IPG Photonics Measuring Instruments show Overheat error?
    • M
      matthew19Aug 21, 2025
      If you see a 'Overheat' error on your IPG Photonics Measuring Instruments, it indicates that the case temperature of the laser is too high. Check if the outside conditions are within the specified range and ensure sufficient airflow. The error message should disappear once the case temperature drops back within the operating range.
  • K
    Kevin SpencerAug 25, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure 2 error?
    • D
      David PatelAug 25, 2025
      If your IPG Photonics Measuring Instruments display a 'Power Supply Failure 2' error, it means that while the internal main power supply is on and voltage is applied to the laser module, the voltage value is outside the expected range. Try resetting the error and ensure the internal main power supply is switched on. If the error continues, contact IPG Photonics for assistance.
  • M
    Mrs. Tracy JohnsonAug 26, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure error?
    • K
      Kimberly JohnsonAug 26, 2025
      If your IPG Photonics Measuring Instruments displays a 'Power Supply Failure' error, it indicates that, despite the internal main power supply being switched on, no voltage is being applied to the laser module. Try resetting the error. If the error persists, contact IPG Photonics for assistance.
  • D
    Donna CarterAug 28, 2025
    What to do if IPG Photonics Measuring Instruments show Module Disconnected error?
    • J
      Jamie RossAug 28, 2025
      If your IPG Photonics Measuring Instruments show a 'Module Disconnected' error, it means that digital data communication with the laser module inside the device is broken. Try resetting the error. If the error appears again, contact IPG Photonics for assistance.
  • K
    Kimberly ChristensenAug 30, 2025
    What to do if IPG Photonics Measuring Instruments show Duty Cycle Too High error?
    • R
      Rebecca AguirreAug 30, 2025
      If your IPG Photonics Measuring Instruments shows 'Duty Cycle Too High' error, the duty cycle is the percentage of how long the laser is in the “on” state in the given modulated period. Check the modulation signal and try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • J
    James SimpsonSep 1, 2025
    What to do if IPG Photonics Measuring Instruments show Internal Communication Error?
    • T
      thomas48Sep 1, 2025
      If your IPG Photonics Measuring Instruments display a 'Internal Communication Error', it occurs when there is no connection to the Controller Area Network (CAN). Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • J
    Jennifer RiosSep 3, 2025
    What to do if IPG Photonics Measuring Instruments show High Pulse Energy error?
    • D
      Daisy BrownSep 4, 2025
      If your IPG Photonics Measuring Instruments show a 'High Pulse Energy' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • M
    Martin StephensSep 5, 2025
    What to do if IPG Photonics Measuring Instruments show Pulse Too Long error?
    • E
      Elizabeth GreenSep 5, 2025
      If your IPG Photonics Measuring Instruments display a 'Pulse Too Long' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • J
    Jennifer DurhamSep 7, 2025
    What to do if IPG Photonics Measuring Instruments show Average Power Too High error?
    • L
      laura26Sep 8, 2025
      If your IPG Photonics Measuring Instruments display a 'Average Power Too High' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.

Summary

Overview of the YLR-Series Fiber Lasers

Safety Information and Conventions

Explains safety symbols, warnings, and conventions used throughout the manual.

Safety Features and Compliance to Government Requirements

Details the laser's safety features and compliance with government regulations.

General Safety Instructions

Covers essential safety recommendations for operating the laser.

Using Your Device

YLR Series - Front Panel View

YLR Series - Rear Panel View

Unpacking Instructions

Provides step-by-step guidance for safely unpacking the laser.

Using the YLR-Series

Covers connecting electrical power and initial system setup.

Interlock Safety Circuit

Explains the laser's safety interlock system and manual reset function.

Interface Connector Pin Assignments

Initial Power-Up Sequence

Outlines the essential steps for the system's initial power-up.

Operation Control Modes

Compares the differences between Local and Remote control modes.

Selecting Operation Modes

Operational Sub-Modes

Computer Interface;Commands

RS-232 Configuration

Details the parameters and setup for RS-232 serial communication.

Ethernet TCP;IP Interface

Explains how to configure and use the Ethernet interface for control.

Interface Commands

Lists and describes the commands used for controlling the laser remotely.

Pulse Shaping

Installing the Pulse Shaper Software

Provides instructions for installing the Pulse Shaper software package.

Configuring a Local Area Connection for Ethernet

Pulse Shaper Configuration Procedures

Explains how to connect to the laser via Ethernet or RS-232.

Using the Pulse Shaper Program

Laser Control Tab

Describes how to activate pulse sequences using the Laser Control tab.

Shape Editor Tab

Guides on creating, editing, and saving pulse shapes.

Scaling Editor

Sequence Editor

Guides on creating and managing pulse sequences for complex output.

Pulse Sequence Activation

Troubleshooting

Error Messages on the Display and Status Bits

Lists common error messages and provides solutions for troubleshooting.

Service

Service and Repairs

Replacing Fuses

Replacing the Filter Media

Optical Fiber Connector Inspection and Cleaning

Overview

Product Returns

Returns to the United States

Returns to Germany

IPG Photonics YLR-1000 Specifications

General IconGeneral
TypeFiber Laser
Wavelength1070 nm
Output Power1000 W
CoolingWater
Mode of OperationCW
