  • E
    Erin Perry DVMAug 19, 2025
    What to do if IPG Photonics Measuring Instruments show High Back Reflection error?
    • J
      Jason GreenAug 19, 2025
      If the Measuring Instruments by IPG Photonics display a 'High Back Reflection' error, it means the back reflected power has exceeded the pre-installed maximal applicable level. First, check that the focus position is correctly adjusted and that there are no surfaces that could cause high back reflection. Then, reset the error using the RS-232 command (“RERR”) or the touch-screen display on the front panel.
  • S
    Steven SmithAug 21, 2025
    Why do IPG Photonics Measuring Instruments show Overheat error?
    • L
      Lisa ArnoldAug 21, 2025
      If you see a 'Overheat' error on your IPG Photonics Measuring Instruments, it indicates that the case temperature of the laser is too high. Check if the outside conditions are within the specified range and ensure sufficient airflow. The error message should disappear once the case temperature drops back within the operating range.
  • G
    Gabriel BradfordAug 25, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure 2 error?
    • K
      kylestevensAug 25, 2025
      If your IPG Photonics Measuring Instruments display a 'Power Supply Failure 2' error, it means that while the internal main power supply is on and voltage is applied to the laser module, the voltage value is outside the expected range. Try resetting the error and ensure the internal main power supply is switched on. If the error continues, contact IPG Photonics for assistance.
  • C
    craig89Aug 26, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure error?
    • T
      Todd ChaneyAug 26, 2025
      If your IPG Photonics Measuring Instruments displays a 'Power Supply Failure' error, it indicates that, despite the internal main power supply being switched on, no voltage is being applied to the laser module. Try resetting the error. If the error persists, contact IPG Photonics for assistance.
  • N
    Nicholas FowlerAug 28, 2025
    What to do if IPG Photonics Measuring Instruments show Module Disconnected error?
    • S
      stephanie84Aug 28, 2025
      If your IPG Photonics Measuring Instruments show a 'Module Disconnected' error, it means that digital data communication with the laser module inside the device is broken. Try resetting the error. If the error appears again, contact IPG Photonics for assistance.
  • D
    denisebakerAug 30, 2025
    What to do if IPG Photonics Measuring Instruments show Duty Cycle Too High error?
    • C
      Christopher OrtegaAug 30, 2025
      If your IPG Photonics Measuring Instruments shows 'Duty Cycle Too High' error, the duty cycle is the percentage of how long the laser is in the “on” state in the given modulated period. Check the modulation signal and try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • A
    andreaoconnorSep 1, 2025
    What to do if IPG Photonics Measuring Instruments show Internal Communication Error?
    • S
      Scott WatkinsSep 1, 2025
      If your IPG Photonics Measuring Instruments display a 'Internal Communication Error', it occurs when there is no connection to the Controller Area Network (CAN). Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • J
    Justin RobinsonSep 3, 2025
    What to do if IPG Photonics Measuring Instruments show High Pulse Energy error?
    • H
      holmesanthonySep 3, 2025
      If your IPG Photonics Measuring Instruments show a 'High Pulse Energy' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • C
    Christine SerranoSep 5, 2025
    What to do if IPG Photonics Measuring Instruments show Pulse Too Long error?
    • C
      catherine14Sep 6, 2025
      If your IPG Photonics Measuring Instruments display a 'Pulse Too Long' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • X
    xmooreSep 7, 2025
    What to do if IPG Photonics Measuring Instruments show Average Power Too High error?
    • A
      andrew01Sep 8, 2025
      If your IPG Photonics Measuring Instruments display a 'Average Power Too High' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.

Summary

1 Overview of the YLR-Series Fiber Lasers

Laser Safety Information and Conventions

Details safety symbols, warnings, and general precautions for operating the laser.

Laser Safety Features and Regulatory Compliance

Covers safety features, EMC, electrical, and laser safety standards compliance.

General Laser Safety Instructions

Provides essential safety recommendations for laser operation and handling.

2 Using Your Device

Laser Unpacking and Electrical Setup

Provides instructions for unpacking the laser and connecting electrical power.

YLR-Series Operation Control Modes

Explains Local and Remote modes, and touch-screen usage.

3 Computer Interface;Commands

Laser Interface Command Reference

Lists and describes the ASCII commands for controlling and monitoring the laser.

4 Pulse Shaping

Pulse Shaper Software Installation and Configuration

Using the Pulse Shaper Program Interface

Pulse Activation Methods

5 Troubleshooting

Laser Troubleshooting: Error Messages and Solutions

Lists common error messages, their causes, and recommended solutions.

A Web User Utility

Web User Utility Configuration and Access

B Service

Laser Service and Maintenance Procedures

IPG Photonics YLR Series Specifications
