IPG Photonics YLR-700 - User Manual

IPG Photonics YLR-700
188 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
HP Switch Software
Part Number: P21-010106, YLR-Series SLED 3.0
Published: April 2015
Revision: B
DCO: 956
Management and Configuration Guide
YLR-Series User Guide
and Configuration Guide

Table of Contents

Questions and Answers

  • D
    Daniel McguireAug 19, 2025
    What to do if IPG Photonics Measuring Instruments show High Back Reflection error?
    • D
      Daniel GreeneAug 19, 2025
      If the Measuring Instruments by IPG Photonics display a 'High Back Reflection' error, it means the back reflected power has exceeded the pre-installed maximal applicable level. First, check that the focus position is correctly adjusted and that there are no surfaces that could cause high back reflection. Then, reset the error using the RS-232 command (“RERR”) or the touch-screen display on the front panel.
  • G
    gutierrezsamuelAug 22, 2025
    Why do IPG Photonics Measuring Instruments show Overheat error?
    • B
      Billy MendozaAug 22, 2025
      If you see a 'Overheat' error on your IPG Photonics Measuring Instruments, it indicates that the case temperature of the laser is too high. Check if the outside conditions are within the specified range and ensure sufficient airflow. The error message should disappear once the case temperature drops back within the operating range.
  • A
    Alyssa FosterAug 25, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure 2 error?
    • C
      Christopher HernandezAug 25, 2025
      If your IPG Photonics Measuring Instruments display a 'Power Supply Failure 2' error, it means that while the internal main power supply is on and voltage is applied to the laser module, the voltage value is outside the expected range. Try resetting the error and ensure the internal main power supply is switched on. If the error continues, contact IPG Photonics for assistance.
  • S
    Stephanie MejiaAug 26, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure error?
    • R
      ronaldrileyAug 26, 2025
      If your IPG Photonics Measuring Instruments displays a 'Power Supply Failure' error, it indicates that, despite the internal main power supply being switched on, no voltage is being applied to the laser module. Try resetting the error. If the error persists, contact IPG Photonics for assistance.
  • T
    Traci WalkerAug 28, 2025
    What to do if IPG Photonics Measuring Instruments show Module Disconnected error?
    • S
      shawn11Aug 28, 2025
      If your IPG Photonics Measuring Instruments show a 'Module Disconnected' error, it means that digital data communication with the laser module inside the device is broken. Try resetting the error. If the error appears again, contact IPG Photonics for assistance.
  • S
    sandra17Aug 30, 2025
    What to do if IPG Photonics Measuring Instruments show Duty Cycle Too High error?
    • J
      jenniferrichardsAug 30, 2025
      If your IPG Photonics Measuring Instruments shows 'Duty Cycle Too High' error, the duty cycle is the percentage of how long the laser is in the “on” state in the given modulated period. Check the modulation signal and try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • D
    Dr. Kimberly GreenSep 1, 2025
    What to do if IPG Photonics Measuring Instruments show Internal Communication Error?
    • M
      Mark EdwardsSep 1, 2025
      If your IPG Photonics Measuring Instruments display a 'Internal Communication Error', it occurs when there is no connection to the Controller Area Network (CAN). Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • M
    Mason GrossSep 3, 2025
    What to do if IPG Photonics Measuring Instruments show High Pulse Energy error?
    • M
      Michael RobertsSep 3, 2025
      If your IPG Photonics Measuring Instruments show a 'High Pulse Energy' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • J
    jason58Sep 6, 2025
    What to do if IPG Photonics Measuring Instruments show Pulse Too Long error?
    • J
      Jack ValdezSep 6, 2025
      If your IPG Photonics Measuring Instruments display a 'Pulse Too Long' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • M
    Michelle GrahamSep 8, 2025
    What to do if IPG Photonics Measuring Instruments show Average Power Too High error?
    • T
      Timothy MeyerSep 8, 2025
      If your IPG Photonics Measuring Instruments display a 'Average Power Too High' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.

Summary

Overview and Safety

Safety Information and Instructions

Explains safety symbols, conventions, general instructions, and optical/electrical safety.

Laser Classification and Labels

Details laser classification standards and the location of safety labels on units.

Using Your Device

Unpacking and Initial Setup

Guides on unpacking, initial power-up, connecting power, and safety circuits.

Operation Control Modes

Describes Local/Remote modes, pulse modes, and touch-screen operation.

Pulse Modes and Touch-Screen Operation

Explains pulse modes (CW, QCW) and touch-screen interface functions.

Computer Interface and Commands

RS-232, Ethernet Configuration, and Commands

Covers RS-232/Ethernet setup and lists interface commands for laser control.

Pulse Shaping

Pulse Shaper Software Installation and Configuration

Step-by-step guide for installing and configuring the Pulse Shaper software.

Shape, Sequence Editing, and Pulse Activation

Details editing shapes, sequences, and activating pulses via software or display.

Troubleshooting

Error Messages and Solutions

Lists common error messages, their causes, and suggested solutions for troubleshooting.

Service, Warranty, and Returns

Service Procedures and Replaceable Items

Information on servicing, repairs, and user-replaceable parts like fuses and filters.

Optical Fiber Connector Cleaning

Detailed guide on inspecting and cleaning fiber optic connectors for optimal performance.

Warranty Terms and Product Returns

Outlines warranty terms, limitations, and procedures for product returns to US/Germany.

IPG Photonics YLR-700 Specifications

General IconGeneral
BrandIPG Photonics
ModelYLR-700
CategoryMeasuring Instruments
LanguageEnglish
