IPG Photonics QCW YLR-1500 - User Manual

IPG Photonics QCW YLR-1500
188 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
HP Switch Software
Part Number: P21-010106, YLR-Series SLED 3.0
Published: April 2015
Revision: B
DCO: 956
Management and Configuration Guide
YLR-Series User Guide
and Configuration Guide

Table of Contents

Questions and Answers

  • J
    Jonathan SmithAug 19, 2025
    What to do if IPG Photonics Measuring Instruments show High Back Reflection error?
    • I
      iadamsAug 19, 2025
      If the Measuring Instruments by IPG Photonics display a 'High Back Reflection' error, it means the back reflected power has exceeded the pre-installed maximal applicable level. First, check that the focus position is correctly adjusted and that there are no surfaces that could cause high back reflection. Then, reset the error using the RS-232 command (“RERR”) or the touch-screen display on the front panel.
  • B
    Bryan HamiltonAug 21, 2025
    Why do IPG Photonics Measuring Instruments show Overheat error?
    • M
      Miss Lindsay CurryAug 21, 2025
      If you see a 'Overheat' error on your IPG Photonics Measuring Instruments, it indicates that the case temperature of the laser is too high. Check if the outside conditions are within the specified range and ensure sufficient airflow. The error message should disappear once the case temperature drops back within the operating range.
  • B
    bcookAug 23, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure 2 error?
    • F
      fprestonAug 23, 2025
      If your IPG Photonics Measuring Instruments display a 'Power Supply Failure 2' error, it means that while the internal main power supply is on and voltage is applied to the laser module, the voltage value is outside the expected range. Try resetting the error and ensure the internal main power supply is switched on. If the error continues, contact IPG Photonics for assistance.
  • S
    shellystevensonAug 26, 2025
    What to do if IPG Photonics Measuring Instruments show Power Supply Failure error?
    • A
      anna00Aug 26, 2025
      If your IPG Photonics Measuring Instruments displays a 'Power Supply Failure' error, it indicates that, despite the internal main power supply being switched on, no voltage is being applied to the laser module. Try resetting the error. If the error persists, contact IPG Photonics for assistance.
  • X
    xmanningAug 27, 2025
    What to do if IPG Photonics Measuring Instruments show Module Disconnected error?
    • R
      Robert RamosAug 27, 2025
      If your IPG Photonics Measuring Instruments show a 'Module Disconnected' error, it means that digital data communication with the laser module inside the device is broken. Try resetting the error. If the error appears again, contact IPG Photonics for assistance.
  • J
    James DoughertyAug 30, 2025
    What to do if IPG Photonics Measuring Instruments show Duty Cycle Too High error?
    • M
      Michelle Huang MDAug 30, 2025
      If your IPG Photonics Measuring Instruments shows 'Duty Cycle Too High' error, the duty cycle is the percentage of how long the laser is in the “on” state in the given modulated period. Check the modulation signal and try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • C
    Cassandra VegaSep 1, 2025
    What to do if IPG Photonics Measuring Instruments show Internal Communication Error?
    • R
      Robert RiversSep 1, 2025
      If your IPG Photonics Measuring Instruments display a 'Internal Communication Error', it occurs when there is no connection to the Controller Area Network (CAN). Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • C
    Cynthia HoweSep 3, 2025
    What to do if IPG Photonics Measuring Instruments show High Pulse Energy error?
    • C
      Christopher GarciaSep 3, 2025
      If your IPG Photonics Measuring Instruments show a 'High Pulse Energy' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • K
    Kristie HughesSep 5, 2025
    What to do if IPG Photonics Measuring Instruments show Pulse Too Long error?
    • S
      Suzanne BarrettSep 5, 2025
      If your IPG Photonics Measuring Instruments display a 'Pulse Too Long' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.
  • E
    ewaltersSep 7, 2025
    What to do if IPG Photonics Measuring Instruments show Average Power Too High error?
    • E
      eric45Sep 7, 2025
      If your IPG Photonics Measuring Instruments display a 'Average Power Too High' error, check the modulation signal. Try to reset the error. If it appears again, contact IPG Photonics for assistance.

Summary

Disclaimer Notice

US Export Control Compliance

Information on US export control compliance requirements for IPG products.

1 Overview of the YLR-Series Fiber Lasers

Safety Information and Compliance

Covers safety info, compliance, features, general instructions, and classification.

2 Using Your Device

Front Panel View and Descriptions

Rear Panel View and Descriptions

Connecting Electrical Power

Instructions for connecting the laser unit to an electrical power source.

Interlock Safety Circuit

Interface Connector Pin Assignments

Operation Control Modes

Explains the differences between Local and Remote control modes.

Device Operation Procedures

3 Computer Interface;Commands

RS-232 Configuration

Ethernet TCP;IP Interface

Interface Commands Reference

Lists and explains commands for controlling the laser via interface.

4 Pulse Shaping

Interface Configuration and Procedures

Program Interface Usage

Explains how to use the Pulse Shaper program interface and its menu items.

Editor Functions (Shape and Sequence)

Pulse Activation and Control

Instructions for activating single pulses, sequences, and using touch-screen control.

5 Troubleshooting

Error Messages and Possible Solutions

Lists common error messages and provides solutions for troubleshooting issues.

B Service

Serviceability and Safety Precautions

Information on serviceable items, safety, and repair procedures.

Component Replacement (Fuses and Filters)

C Optical Fiber Connector Inspection and Cleaning

Overview, Materials, and Procedure

Overview of fiber connector inspection, cleaning materials, and procedure.

E Product Returns

Returns to United States and Germany

IPG Photonics QCW YLR-1500 Specifications

General IconGeneral
BrandIPG Photonics
ModelQCW YLR-1500
CategoryMeasuring Instruments
LanguageEnglish
