IPS Controllers M820 User Manual

Figure 1: This is a typical installa on using IPS’ system package, which consists of an
M820 pH/dual ORP Controller,  ow cell with switch, and two pumps mounted on the large board.
6
M820 pH/Dual ORP Controller Owner’s Manual
Chemical
Pump
Chemical
Pump
Flowcell (1)
Sucon Line
FLOW
FLOW
FLOW
Effluent (to Sucon)
Waste
Influent (to Return Line)
Filter
Pump
FLOW
Filter
(10)
(aach to pipe with clamps)
FLOW
FLOW
Sample
pH sensor (3)
ORP
Sensor
(4)
Typical Installaon
Note: All chemical must be injected downstream from
the heater and flowcell.
Main Drain and Skimmer
Pressure Differenal
Return Line
FC100G FLSW SXPH SXORP SXORP-G Valve Jaco Fing 1/2” Jaco Fing 1/4” 38tubing Filter
1 2 3 4 5* 6 7 8 9 10
Flow Cell, Complete Flow Switch Only pH Sensor ORP Sensor (Standard Planum Tip) ORP Sensor (Gold-Tip for Salt Pools) 2-way Flow Cell Valve 1/2” Jaco fing for sensors 1/4” Jaco fing for tubing 3/8” tubing for plumbing to/from Flow Cell Filter Strainer
IPS Parts List
Flow Switch (2)
1/2” Jaco Fing (7)
38tubing (9)
Valve (6)
* not shown
1/4” Jaco Fing (7)
