IPSO DR75 - DR75 Dryer Dimensions - Gas (Illustration)

Page 11
DR75 Dryer Dimensions - Gas
(Illustration)
38.97“ (990 mm)
75.19“ (1910 mm)
33.07“ (840 mm)
5
3
.
34“(13
55 mm
)
14
.
7
9
.
1“(230
mm
)
9.25“(235 mm)
7.87“(200 mm)
13“(330 mm)
EXHAUST
16.33“(415 mm)
9.1“(230 mm)
ELECTRIC
BOX CON.
Electric
Inlet
Steam Conn.
Gas Conn.
Steam Ret.
10.82“(275 mm)
9.84“(250 mm)
4.96“(126 mm)
8.5“(215 mm)
Connection
