Tumblers – T30 and T45
18
4-08-43
Electrical Requirements for Gas and
Steam Models
Refer to Table 4 and Tabl e 5.
NOTE: Minimum wire sizes are obtained from
Canadian Electrical Code for 75°C Conductors
and are intended for use as a guideline only.
Electrical connections should be made only by a
qualified electrical contractor in accordance with
all applicable local and national requirements.
For T30 Gas and Steam Models
(For Total Machine):
NOTE: Electrical specifications below are subject
to change without notice. Always refer to product
serial plate for most current specifications of
product being installed.
NOTE: Use copper conductors only.
NOTE: 3 Phase Only – Each tumbler must be
connected to its own individual branch circuit
breaker, not fuses, to avoid the possibility of “single
phasing” and causing premature failure of the
motor(s).
Table 4
Serial Plate Voltage
Terminal Block
Connections
Required
Current
(Amps)
Recommended
Fuse or
Breaker Rating
(Amps)
Breaker
Poles
Recommended
Minimum
Conductor Size
(AWG [mm
2
])
120V/60 Hz/1ph
L1, Neutral,
and ground
16.0 20 1 12 (3.31)
208-240V/60Hz/1ph
L1, L2, Neutral,
and ground
8.0 10 2 14 (2.08)
100V/60Hz/1ph
L1, Neutral,
and ground
22.0 30 1 10 (5.26)
200-220V/60Hz/1ph
L1, Neutral,
and ground
11.6 15 1 14 (2.08)
100V/50Hz/1ph
L1, Neutral,
and ground
24.2 35 1 8 (8.37)
200V/50Hz/1ph
L1, Neutral,
and ground
15.0 20 1 12 (3.31)
230-240V/50Hz/1ph
L1, Neutral,
and ground
15.0 20 1 12 (3.31)
200-208V/60Hz/3ph
L1, L2, L3,
and ground
6.4 10* 3 14 (2.08)
240V/60Hz/3ph
L1, L2, L3,
and ground
6.4 10* 3 14 (2.08)
200V/50Hz/3ph
L1, L2, L3,
and ground
5.8 10* 3 14 (2.08)
230-240V/50Hz/3ph
L1, L2, L3,
and ground
7.0 10* 3 14 (2.08)
380V/50 or 60Hz/3ph
L1, L2, L3,
and ground
3.0 10* 3 14 (2.08)
400-415V/50Hz/3ph
L1, L2, L3,
and ground
3.2 10* 3 14 (2.08)
460-480V/60Hz/3ph
L1, L2, L3,
and ground
3.3 10* 3 14 (2.08)
* 3 Phase machines should not have fuses, breakers only.
