 Long press M+C button to achieve stadiametric rangefinder. After entering the
menu of stadiametric rangefinder, press P + C button to adjust the scale plate to
move up and down, and long- press M button to exit.
6. Specification
Model
SCL25
SCL35
Resolution, pixels
384×288
Pixel size, μm
17
NETD, mk
≤40
Frame rate, Hz
50
Objective lens, mm
25
35
Field of view
14.9°× 11.2°
10.7°× 8.0°
Display
1280×960 LCOS
Magnification, x
1.4-5.6
2.0-8.0
Battery type
CR123×2
Max. Operation time, h
4
Weight (without batteries), g
＜410
Dimension, mm
176×6 1×61
195×61×6 1
Detective range, m
(Target size:1.7m*0.5m, P(n)=99%)
916
1283
USB type
Type C
