Page 3 of 16
BBC067 / BBCD067 / BBA067 / BBT067-NLInstallation Guide
©Copyright 2018 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
6. Open the inner holes to 12mm
5. Drill holes using a 21mm hole saw,
only through outer skin of chassis
cross member.
Drill a pilot hole using the centre
drill bit of the hole saw through the
inner skin as shown.
To Next Page
