5. Connect the thin black earth wire
and negative battery cable to the
earth connection on the opposite
side of winch motor.
7. Connect positive and negative
battery cables main battery of
vehicle (Not Auxilliary Battery).
8. Attach breather hose to barb fitting
on winch motor. Run hose to the
highest available point in engine
bay and cable tie in position. Cable
tie hose away from any sharp, hot
or moving objects.
Refer back to step 18 of the Bull
Bar fitting instructions on page 7
6. Run the positive and negative
battery cables into the engine bay
taking care to secure cables away
from any sharp or moving objects.
