iRoom iDock - iRooms miniDock Quick Start Guide; Flush-mounted Box Installation for miniDock

Page 4 Page 5
English
Option I: LAN & 110-240V AC Option II: PoE
+
(IEEE802.3at)
1
2
3 4
Installation of Flush-mounted box
The iRoom‘s miniDock may only be used
with the Backbox! The Backbox is not
included in the scope of delivery and must
be purchased separately. Operating the
device without the Backbox leads to a loss
of warranty rights. Use for purposes not inten-
ded by the manufacturer will void warranty.
For detailed description please refer to the
"Backbox installation manual".
Quick Start Guide
iRoom‘s miniDock
The Backbox design and method of installation differs on speci c models.
center the insert and
center the insert and
tighten the screw gently to
tighten the screw gently to
avoid bending and ensure
avoid bending and ensure
proper  tting of glasbezel
proper  tting of glasbezel
This particular model can be installed either in landscape or in portrait orientation.
Please proceed with setting up your miniDock using the iOS App
″iRoom‘s iDock″
