Irritrol Rain Dial-R Quick Start Guides

3
Battery Installation
Install a 9V battery for two reasons:
1. Program the controller
from any location.
2. Maintain controller time
and date during power
outages.
Steps:
1. Open controller door.
2. Slide battery
compartment cover off.
3. Attach the battery clip
to a 9V battery.
4. Install battery into
compartment and
replace cover.
5. The display will begin
flashing 12:00 AM.
EARTH
GROUND
MV/
PUMP
7 8
9 10 11 12
1 2 3 4 5 6
24 VAC
VC
1
2
3
4
5
6
7
English

Irritrol Rain Dial-R Specifications

General

Brand	Irritrol
Model	Rain Dial-R
Category	Controller
Language	English
