Irrtitrol Rain Dial RD-600 User Manual (English)

Questions and Answers:

D
Daniel SmithJul 27, 2025
What to do if no valves operate on my Irrtitrol Controller?
- M
  Mrs. Jennifer SantosJul 27, 2025
  If no valves are operating, several issues could be the cause. First, check that the Function Switch is set to either the Run or Manual position, not OFF. A defective valve solenoid could also be the problem, so test and replace it if necessary. Ensure all wire connections are secure, paying special attention to the common wire or “VC” connection. Also, verify that the current day is correctly set in the display and that Skip Days are programmed correctly. Make sure Start Times are properly set and that Rain Delay is turned off.
E
Erika PierceJul 31, 2025
Why is the current time wrong and flashing on my Irrtitrol Controller?
- C
  coreyhodgesJul 31, 2025
  If the current time is wrong and flashing, and the display shows “FUS” and a station number, it usually indicates a power outage occurred without battery backup. Install or replace the battery and then reset the time. Another possible cause is excessive current load due to a shorted wire or defective solenoid. Inspect the wiring and splices for a short circuit and replace any defective solenoids.
B
bennettcharlesAug 5, 2025
What to do if my Irrtitrol Rain Dial RD-600 program won’t display?
- B
  Brittany WarnerAug 5, 2025
  If the program won’t display on your Irrtitrol Controller, ensure the Function switch is in the Run position. Also, if the controller is currently in a watering cycle, you will need to check or change the program with the Function switch in the Set Programs position.
G
Grace JohnsonAug 9, 2025
How to reset the Irrtitrol Rain Dial RD-600 display after a power outage?
- T
  Tina JonesAug 9, 2025
  If your Irrtitrol Controller displays incorrect information after a power outage or being unplugged, the battery may be weak, dead, or not installed. Remove AC power and the battery for one minute. Then, install or replace the battery and restore power.
M
Maria BeltranAug 13, 2025
What to do if some valves do not operate on my Irrtitrol Rain Dial RD-600 Controller?
- J
  Jennifer GrimesAug 13, 2025
  If some of the valves do not operate, it could be due to a defective solenoid or a loose wire connection. Test and replace the solenoid if necessary. Also, ensure that all wire connections are secure and check for connection continuity.
C
cdavisAug 17, 2025
Why is my Irrtitrol Rain Dial RD-600 Controller display blank?
- C
  Carl PerryAug 17, 2025
  If your Irrtitrol Controller display is blank, it indicates a loss of power. Check the circuit breaker panel, wiring connections, transformer, and the 2A fuse.

Irrtitrol Rain Dial RD-600 Specifications

General

Type	Irrigation Controller
Model	RD-600
Stations	6
Power Source	AC
Voltage	24 VAC
Rain Delay	Yes
Rain Sensor Input	Yes
Programmable Start Times	4
Watering Programs	3
Display Type	LCD
Battery Backup	Yes
Outdoor Use	Yes
Watering Duration	1 minute to 6 hours

Summary

Key Features of the Rain Dial Controller

Modular Design

Physical design providing easy access to valve wiring and battery, with a snap-out control module.

Non-Volatile Memory

Maintains user-defined watering program information without power.

Independent Watering Programs

Enables setting different watering routines for trees, lawns, and gardens.

Skip Days Scheduling

Determines watering days by frequency, from 1 to every 31 days.

Rain Delay Feature

Postpones automatic watering up to 9 days, then resumes schedule automatically.

Water Budget Feature

Adjusts all station run times within a program by percentage (0-200%).

Diagnostic Circuit Breaker

Detects and bypasses stations with short circuits, displaying 'FUS' for troubleshooting.

Getting Started

Battery Installation & Armchair Programming

Instructions for installing the 9V battery and programming the controller before installation.

Installation Procedures

Installing the Controller Cabinet

Steps for mounting the controller unit to a wall or suitable location.

Connecting the Valve Wires

Guide to wiring the irrigation valves to the controller terminals.

Connecting the Earth Ground

Procedure for establishing a proper earth ground connection for controller protection.

Connecting the Power Source (Indoor Models)

Instructions for connecting the power supply for indoor controller units.

Connecting the Power Source (Outdoor Model)

Instructions for connecting the power supply for outdoor controller units.

Station Test Run Feature

How to perform a test run of all stations in sequence after installation.

Getting the Most from Your Rain Dial Controller

Basic Programming Procedures

Setting Current Time and Day

Steps to accurately set the controller's current time and day of the week.

Setting Valve Run Times

Configuring the watering duration for each station within a selected program.

Setting Program Start Times

Defining up to three daily start times for each watering program.

Watering Day Scheduling Options

Options for setting watering days: Weekdays, Skip Days, or Odd/Even Date.

Day Exclusion Feature

Excluding specific weekdays from Skip Days or Odd/Even watering schedules.

Special Functions and Features

Rain Delay Feature

Temporarily suspends automatic watering for 1 to 9 days.

Water Budget Feature

Adjusts all station run times within a program by percentage (0-200%).

Stack/Overlap Control

Manages simultaneous or sequential operation of programs/stations.

MV/Pump Control per Station

Controls Master Valve/Pump circuit based on individual station needs.

Diagnostic Circuit Breaker

Detects and bypasses stations with short circuits, displaying 'FUS' for troubleshooting.

Factory Default Reset

Restores controller settings to their original factory defaults.

Manual Operations

Semi-Automatic Operation

Manually starts a selected program watering cycle with manual advance.

Manual Station Operation

Manually operates individual stations for a one-time run duration.

Troubleshooting

Valve and Operation Issues

Diagnosing and correcting issues with valve operation, including non-responsiveness and failure to shut off.

Display and Timing Problems

Resolving issues related to incorrect timing, blank displays, program visibility, and error messages.

Replacing the Fuse

Remote Control Feature

Specifications

FCC Rules
