ISA T2000 - Page 17

DOC. SIE10110 Rev. 6 Page 18 of33
LEVEL1
LEVEL 2
LEVEL 3
LEV. 4
FUNCTION
TEST
CONTROL
Test
mode
Normal (default)
Measures the time delay from test START to
STOP (internal, external).
Trip + pulse time
Measures the time delay from test START to
STOP (internal, external), and the duration of
STOP.
Fault
injection
Maintained (default)
Generation lasts indefinitely
Momentary
Generation lasts until the ON button is pressed
Timed
Max time
Generation lasts for the pre-set time duration. Max
time 999 s.
OFF
delay
T delay
The main output OFF is delayed by the set amount
of time or cycles.
Output
power
300 VA (default) –
60 VA
Selection of full (300 VA) or reduced (60 VA)
power
Save
Don’t save (default)
Test data are not saved
Automatic, at trip
As relay trips data are saved to the next memory
location
Confirm, at trip
As relay trips data can be saved, after confirmation
Manual
When selected, generated values are saved.
Auxiliary
contact
Timing
Sets the contact timing with respect to test start
