ISA T2000 - Page 18

DOC. SIE10110 Rev. 6 Page 19 of33
LEVEL
1
LEVEL
2
LEVEL
3
LEVEL
4
FUNCTION
TIMER
STOP
Stop
INT
Timer stops when the current of the main generator
is interrupted.
EXT
(def.t)
NO-NC-
EDGE (def.t)
Timer stops when the STOP input is detected.
External STOP input Normally Open or Normally
Closed or Both (EDGE).
CLEAN-24 V
– 80 V
Timer stops when the STOP input is detected.
External STOP input without or with voltage. If
with voltage, two voltage thresholds are available:
24 or 80 V.
Timer
s (default)
Time duration metered in seconds
cycles
Time duration metered in cycles
LEVEL 1
LEV. 2
LEVEL 3
LEVEL 4
FUNCTION
METERS
Internal
Units of I
Normal
If selected, current values are displayed
in A.
I/IN
IN
If selected, displayed values are defined
as I/IN, that can be defined.
Units of V
Normal
If selected, voltage values are displayed
in V.
V/VN
VN
If selected, displayed values are defined
as V/VN (phase voltage), that can be
defined.
External
I
Enabled
AC (default) - DC
With selection AC the meter performs
the true rms measurement; with
selection DC, the measurement is
performed on the average.
10A – 20 mA
Selects the current input socket
Waveform
If selected, the current waveform is
displayed
External
V
Enabled
AC (default) - DC
With selection AC the meter performs
the true rms measurement; with
selection DC, the measurement is
performed on the average.
Shunt : 1 – 1000 mOhm
If the voltage is coming from a current
dropping on a shunt, specifying the
shunt value the current is displayed;
default 100 mOhm.
Waveform
If selected, the voltage waveform is
displayed
