PB 110 - 53
TAV.
TABLE
RIF.TO
REF.
CODICE
PART No.
DESCRIZIONE DESCRIPTION
1 1 2103423 Telaio Chassis
1 2 4300033 Vite TE M8 x 20 Screw M8 x 20
1 3 4200079 Ruota 150 x 40 Wheel 150 x 40
1 4 4300053 Dado M8 autofrenante Self-locking nut M8
1 5 3000417 Piatto ferma cassetto Hopper fastener
1 6 4300036 Rondella diam. 8,4 Washer diam. 8,4
1 7 2100525 Cassetto Hopper
1 8 3000376 Flap cassetto Hopper dust flap
1 9 3000191 Piatto ferma flap Flap fastener
1 10 4300079 Dado medio M6 Nut M6
1 11 4300047 Vite TE M6 x 16 Screw M6 x 16
1 12 3003404 Carter inferiore sinistro Left side carter
1 13 4300173 Vite TBEI M6 x 20 Screw M6 x 20
1 14 2103403/A Carter inferiore destro Right side carter
1 15 3002244 Protezione ventola Fan protection
1 16 2103426 Scuotifiltro Filter shaker
1 17 4200129 Molla Spring
1 18 4200358 Volantino Handle
1 19 2101459 Copertura filtro Filter cover
1 20 3000597 Filtro Filter
1 21 4200249 Galletto M8 Special screw M8
1 22 3002171 Guarnizione chiusura convogliatore Conveyor closing gasket
1 23 2103379 Manubrio Handle
1 24 3003429 Cofano PB 70 ET Bonnet PB 70 ET
1 25 3000294 Cavo in acciaio per cofano Cable for bonnet
1 26 4300222 Vite TBEI M8 x 20 Screw M8 x 20
1 27 4300228 Dado bombato M6 Nut M6
1 28 4300055 Vite TE M4 x 16 Screw M4 x 16
1 29 4300049 Rondella diam. 4,3 Washer diam. 4,3
1 30 4300056 Dado M4 autofrenante Self-locking nut M4
1 31 4300048 Rondella diam. 6,4 Washer diam. 6,4
1 32 2103468 Carrter superiore destro Upper rifgt carter
1 33 4200629 Cerniera zincata quadra Hinge
1 34 3002249 Spessoramento cerniere Hinge shim
1 35 4300040 Vite TE M8 x 40 Screw M8 x 40
1 36 4300029 Dado medio M8 Nut M8
1 37 3003131 Etichetta “ISAL PB 70” “ISAL PB 70” label
1 38 4200014 Maniglia per cofano Bonnet handle
1 39 4300052 Vite TCEI M 8 x 20 Screw M 8 x 20
3 1 4200243 Coperchio volante Steering wheel cap
3 2 4300107 Vite TE m 8 x 15 Srew M8 x20
3 3 3000098 Rondella speciale Special washer
3 4 4200175 Volante Swteering wheel
3 5 4200104 Linguetta 5 x 15 Key 5 x15
3 6 3000811 Piantone sterzo Steerig column
3 7 4200621 Giunto nadella diam.17 Joint diam . 17
3 8 4300105 Spiana elastica Elastic pin
3 9 4300102 Seeger diam..17 Seeger diam. 17
3 10 4200005 Cuscinetto 6203 Bearing. 6203
3 11 3000775 Supporto albero pignone Pinion shaft support
3 12 2100815 Supporto ruota anteriore Front wheel support
3 13 4300036 Rondella diam. 8 Washer diam 8
3 14 2100808 Pignone Pinion
3 15 3000751 Catena Chain
3 16 2100870 Corona Crown Wheel
3 17 4200151 Cuscinetto 3205 2RS Bearing 3205 2 RS
3 18 4200150 Cuscinetto 6204 2RS Bearing 6204 2RS
3 19 4300039 Rondella diam. 17 x 30 Washer diam. 17x 30
3 20 4300038 Dado M16 Autofrenante Self-locking nut M16
3 21 4300040 Vite TE M8 x 40 Srew M8 x 40
3 22 4300029 Dado M8 Nut M8
3 23 2100835 Forcella Fork
3 24 4300115 Vite TE M 12 x 160 Screw M12 x 160
3 25 4300058 Rondella diam. 13 x 24 Washer diam. 13 x 24
3 26 4200112 Dado M12 autofrenante Self-locking nut M12
3 27 3000826 Distanziale Spacer
3 28 4200207 Coperchio mozzo Brake block
3 29 3000825 Distanziale Spacer
3 30 4200240 Cuscinetto 6301 2 RS Bearing 6301 2 RS
3 31 4200241 Semocerchio Rim
3 32 4200242 Anello in gomma anteriore Front rubber ring
3 33 4200147 Semicerchio Rim
3 34 3000937 Distanziale esterno External spacer
3 35 4300114 Groover diam. 8 Groover washer diam .8
3 36 4300052 Vite TECEI M8 x20 Srew M8 x 20
3 37 4200148 Gomma piena Rear rubber ring
3 38 2100853 Mozzo con cerchio Hub with rim
3 39 4200058 Linguetta 6 x 30 Key 6 x 30
3 40 4200176 Motoriduttore 24 V - 400 W Motor gear box 24 V - 400 W
3 40/A 3000955 Semiasse lungo Long axle shaft
3 40/B 3001482 Semiasse corto Short axle shaft
3 40/C 4200601 Sapzzole per motoriduttore 24 V Brushes for motor gear box 24 V
3 41 4300192 Groover diam. 6 Groover washer diam. 6
3 42 4300047 Vite TE M6 x 16 Screw M6 x 16
3 43 4200050 Supporto BPFL 204 Bearing SBFL 204
3 44 4200034 Supporto SBPP204 Bearing SBPP 204
3 45 4200208 Morsetto freno Brake clamp
3 46 4200209 Registro M6 Adjustment M6
3 47 4200024 Guaina Sheating
3 48 4200025 Fermo per guaina Sheating stop
3 49 4200153 Filo frizione diam.2.5 Clutch cable diam .2.5
3 50 3001018 Perno Rod
3 51 4200004 Molla Spring
3 52 4200210 Freno a mano Hand brake
3 53 2101729 Supporto volante Steerinf wheel support
3 55 2100884 Pedale freno Brake pedal
3 56 4300110 Vite TE M10 x 50 Screw M10 x 50
3 57 4300070 Dado M10 antufrenante Self lockimg nut M10
3 58 2101802 Colonna comandi Culumn
3 59 3001797 Pannello comandi Dashboard
3 60 4300173 Vite TBEI M6 x 20 Screw M 6 x 20
3 61 3001763 Coperchio colonna Culumn cover
3 62 3000958 Braccio freno Brake arm
3 63 4300108 Vite TE M 8 x 30 Screw M 8 x 30
3 64 4300036 Rondella diam. 8 Washer diam 8
3 65 4300053 Dado M8 antofrenante Self- locking nut M8
3 66 4300126 Rondella dian. 8 x 24 Washer diam. 8 x 24
3 67 3000936 Barra freno Brakr shaft
3 68 4200052 Morsetto serralo Clamp for cable
