Isal PB 110 E - 12. SWEEPER MOVEMENT AND BRAKING; Forward, Backward Movement, and Service Brake

PB 110 - 18
12
Il pedale part. 1 Fig. 12 serve per fare
avanzare la macchina.
Il pedale part. 2 Fig. 12 serve per fare
arretrare la macchina.
FRENO DI SERVIZIO
Il Part. 3 Fig. 12 serve per frenare la
macchina.
• AVANZAMENTO ARRETRAMENTO
MACCHINA
( SPECIFICA PER MODELLO 110 E )
• MOVING THE SWEEPER
BACKWARDS AND FORWARDS
( SPECIFICALLY FOR MODEL PB 110 E )
Pedal, item 1 Fig. 12 is used to move the
sweeper forwards.
Pedal, item 2 Fig. 12, is used to move the
sweeper backwards
SERVICE BRAKE
Item 3, Fig. 12 is used to brake the swee-
per.
3
2
1
➟
