EHS E08F2 4.xx 4.28 (or higher)
EHS E08F2 6.xx 6.51 (or higher)
EHS E08F7 1.xx 1.00 (or higher)
EHS E16C1 1.xx 1.19 (or higher)
EHS E16C1 2.xx 2.13 (or higher)
EDS E16D0 4.xx 4.43 (or higher)
EDS E16D1 4.xx 4.43 (or higher)
EDS E24D1 5.xx 5.52 (or higher)
9 WiFi
The CC24 Master crate controller is optionally equipped with a removable WiFi access point.
In case this feature is unwanted, you can switch it off by software configuration (see iCSconfig) or remove the USB-hardware part
from the controller board or front panel USB port.
For more information of WiFi configuration and use, refer to the iCS section (see page 18)
10 Module Bitrate Configuration
INFORMATION
NOTE
All modules must be configured to a CAN bitrate of 250 kBit/s for operation with CC2x controller series.
If modules are configured to a CAN bitrate of 125 kBit/s, they can be re-configured by the crate controller
in a special regime. In this regime, the LED STATUS blinks green.
Please follow these steps to prepare modules for use with CC 2x crate controller series:
1. Please read all steps before starting the process!
2. Crate is connected to mains, the crate is turned off, no module is plugged into a slot
3. No connector is plugged into the CONTROL socket of CC 2x crate controller
4. Press and hold the button POWER-ON for about five seconds
5. The LED STATUS blinks slowly GREEN
6. If a module is recognized now, the controller switches into normal operation mode
◦ If no module is recognized, the controller enters CONFIGURATION MODE
7. The LED STATUS blinks quickly, the controller scans for a module at both bitrates
8. Insert exactly one module which bitrate should be adapted (by hot plugging).
◦ If the module is recognized on the wrong bitrate (i.e.125kBit/s), it will programmed to the correct bitrate
(250kBit/s) and restarted afterwards
9. If the module is (now) recognized at the correct bitrate, the LED STATUS blinks slowly
10. The module can be plugged out now and another module can be plugged in to repeat the configuration process from
step 5
11. Press the button POWER-ON for about one second to turn off the crate and exit the CONFIGURATION MODE
