6. Please wait about 20 seconds until iCS has started completely
7. optional: Plug off the USB flash drive and check on a computer if the file created on point 2 is still there.
Check if RESET_NET.txt was renamed into RESET_NET.txt.done on success.
WiFi configuration
The WiFi configuration can change configuration of the wireless network provided by the iCS hardware access point (optional).
Generally the WiFi function can be disabled using the WiFi support switch. The IP address of the WiFi is fixed, so once connected
with a iCS WiFi the IP stays always the same.
WIFI FACTORY DEFAULTS
IP (fixed) 192.168.1.1
SSID iseg-iCS2_[HARDWARE SERIAL-NUMBER ]
Channel 5
Password password
Users / roles configuration
Users of iCScontrol can be added, edited and removed in the users section. Users of iCScontrol can be added, edited and
removed in the users section. Users can be assigned roles, such like admin, user etc. One or more users can be selected by
editing a role.
USER DEFAULTS
User admin
Password password
Role admin
Access control lists (ACL)
With the access control list rights to grant or forbid control on special objects for principals (roles or users) is managed. This gives
a powerful tool for very detailled right mechanism.
INFORMATION
NOTE
Note: Users, roles and ACL are only applied for user authentication for applications and services, which
are based on iCSservice. These are iCScontrol, iCSconfig, isegControl, SOAP and HTTP API.
isegHAL based services should implement own security mechanisms .
SSH access
The ICS2 Linux host system can be fully accessed as root user using a encrypted SSH shell access over port 22.
This enables user to install own services or freely configure, e.g.EPICS plugins etc.
INFORMATION
The local filesystem is divided into a system and a user data partition. To make changes on the readonly
