Right bar: Device information
The device section gives information on the currently selected hardware device of the device explorer. Depending on the device
type, hardware status information are given (temperature, error, safety loop states), the device can be enabled / disabled. Device
specific parameters can be set (ramps, kill parameters …). To get a quick help, hardware documentation can be downloaded
directly.
Right bar: Camera
The camera tab shows the captured image of the configured camera. It can be directly connected with the iCS hardware or an IP-
Cam URL, configured in hardware / iCScontrol section.
Right bar: Live log
The live log collects information of the current session. The log data is only available until a reload of the iCScontrol webpage
occurs. The live log can be filtered to specific channels or value types, by selecting channels and clicking the corresponding log
icon in the action row on top of the channel list. The log list shows the last value of an item. By clicking on it, previsios log items
are displayed.
All session log data can be exported as CSV file for ongoing work with Spreadsheet applications, eg. Microsoft® Excel.
Right bar: Commands
Commands can be send directly to connected devices. Quick commands are mass operations that can be sent to more devices at
one time. The commands tab prefills the input fields according to the selected hardware device (device explorer).
13 Appendix
For more information please use the following download link:s
CAN EDCP Programmers-Guide
http://download.iseg-hv.com/documentation/SYSTEMS/Manuals/English/MMS/CAN_EDCP_Programmers-Guide.pdf
