Isel iMC Series - 2 Controller Types

iMC-B / iMC-V Operating Instruction
page - 6
2 Controller types
Controller
type
Motor type
power
amplifier
max. axis
iMC-B
Brushed isel - DC-servo-motors (BDC)
iMD10
6
iMC-V
Brushless isel - DC-servo-motors (BLDC)
iMD20
6
All controllers have to be used only with the compatible motor type.
Please read this operation instruction manual carefully before first use of the
controller.
Scope of delivery - iMC-B (Part.-No. 354000 10X
1
0)
 Servo-controller iMC-B as desk device with the following components:
o 2 - 6 integrated power amplifiers iMD10 for brushed DC-servo-motors
(B-DC) /1/
o Control PC iSR10 with CAN PCI card iCC10
o CAN IO 16/16 module
o Security circuit module iSM5 (not useable on CAN bus)
 10,2” LCD with touch screen and mini keyboard in the case front
 Main cable (protection contact plug, IEC-60320 power connector)
 RS232-communication cable, 9-pin Sub-D (plug) to RJ45 (plug)
 Connector package
 Control software Remote (option: ProNC)
 Operating instruction in printed form
 Option: frequency inverter 750W for working spindle,
 max. 4 axis possible
Scope of delivery - iMC-V (Part.-No. 354000 20X
1
0)
 Servo-controller iMC-V as desk device with the following components:
o 2 - 6 integrated power amplifiers iMD20 for brushless DC-servo-
motors (BL-DC) /2/
o Control PC iSR10 with CAN PCI card iCC10
o CAN IO 16/16 module
o Security circuit module (not useable on CAN bus)
 10,2” LCD with touch screen and mini keyboard in the case front
 Main cable (protection contact plug, IEC-60320 power connector)
 RS232-communication cable, 9-pin Sub-D (plug) to RJ45 (plug)
 Connector package
 Control software Remote (option: ProNC)
 Operating instruction in printed form
 Option: frequency inverter 750W for working spindle,
 max. 4 axis possible
1
X-number of power amplifiers, 2 - 6
