Isel iMC Series - 3 Technical Data

iMC-B / iMC-V Operating Instruction
page - 7
3 Technical data
controller
iMC-B
iMC-V
servo-motor type
BDC-servo-motors (brushed DC)
BLDC-servo-motors (brushless DC, EC)
maximum number of axis
6
6
power supply
115-230 VAC, 50 … 60 Hz
115-230 VAC, 50 … 60 Hz
power supply output
1000 W
1000 W
motor power amplifier
iMD10
iMD20
intermediate circuit power supply
48 VDC
48 VDC
rated current
12 A
12 A
peak current
25 A
25 A
safety category
3
additional safety functions
integration in higher ranked security circuit , safety door control, working spindle control
I/O-extension-board
16 x digital inputs (8 inputs useable, 8 inputs internal used)
16 x digital outputs (8 outputs useable, 8 outputs internal used)
1 x 115-230V relais output (max. 6 A)
option: 1 x analog output (8 Bit, 0 …10 V)
TFT-display
10,2 “ TFT-display with touchscreen
Integrated keyboard
mini keyboard
control PC
1,6 GHz-processor
RAM ≥ 1 GB
hard disk 2,5“ SATA ≥ 80 GB^
2 x USB 2.0 in case front
operation
function keys, emergency stop
operating system
WEPOS
®
2009
software
Remote (option: ProNC, isyCAD/CAM)
Dimensions W x H x D
625 x 225 x 375
625 x 225 x 375
