Iso-Tech IDM 103N - Meter Description

10
Power On/Off
COMMON Input
C
Input
mA InputA
Features
Functions &
Display
The Meter Description
Front Panel Illustration
1. 4000 counts LCD display.
2. Push-buttons for features.
3. Rotary switch to turn the Power On or Off and to select a
function.
4. Input Terminal for A current function
5. Input Terminal for all functions EXCEPT current (A)
functions
6. Common (Ground reference) Input Terminal for all functions.
