20
(4) Peak HOLD (For IDM99-III only)
Specied accuracy ±150d.
(5) Resistance
Input Protection : 1000VDC or 1000VAC rms
Max. Open Circuit Voltage : Approx. 2.5V for 600Ω & 6kΩ Range.
Approx. 0.6V for others.
Max. Test Current : Approximately 0.1mA.
* There is a little rolling less than ±50 digits when measuring ＞ 10.00MΩ.
(6) Continuity Check
Input Protection : 1000VDC or 1000VAC rms
Max. Open Circuit Voltage : Approx. 2.5V
Max. Test Current : Approx. 0.1mA
Continuity Threshold : ＜30Ω Beep On.
＞100Ω Beep OFF.
Continuity Indicator : 2.7kHz Tone Buzzer
IDM98-III/IDM99-III
Range Resolution Accuracy
600.0Ω 0.1Ω ± (0.8% + 5d)
6.000KΩ 0.001KΩ
± (0.8% + 2d)
60.00KΩ 0.01KΩ
600.0KΩ 0.1KΩ
6.000MΩ 0.001MΩ
40.00MΩ* 0.01MΩ ± (1.0% + 5d)
IDM98-III/IDM99-III
Range Resolution Accuracy
600.0Ω 0.1Ω ± (0.8% + 5d)
