Iso-Tech ILCM 06 - Auto Range; Manual Range

8
ILCM 06 English
(forcing into the manual range mode)
• The cut-off frequency of the low pass lter is
about 100Hz with attenuation characteristic of
approx. –24dB/octave.

(forcing into the manual range mode)
Press > 1sec
Press < 1sec
50/60 Hz
Mode
Wide Mode
20.0A / 400Hz
Press
20.0A / 400Hz
Press < 1sec
to change
the range
Press
Press > 1sec
20A
I
20A
I
