IPS X303 Series Instruction Manual
18
CH2
CV/CC/PAR
Indicator
C.V. C.C. PAR.
0 30V , 3A
CH2
SLAVE
SERIES
Indicates CH2 Constant Voltage, Constant
Current, or Tracking Parallel operation mode.
CH2 Output
Outputs CH2 voltage and current.
CH3 Overload
Indicator
CH3
C.C.C.V.
0 5V , 3A
5 10V , 1A
Indicates CH3 Constant Voltage or Constant
Current state for the IPS 4303S.
CH3 Output
Outputs CH3 voltage and current.
CH3 Overload
Indicator
LOAD
OVER
Indicates when CH3 (IPS 3303S) output current is
overloaded.
CH3 Voltage
Selector
, 3A
3.3V2.5V 5V
Selects CH3 output voltage for the IPS 3303S:
2.5V, 3.3V, or 5V.
CH4 CV/CC
Indicator
CH4
C.C.C.V.
0 5V , 1A
Indicates CH4 constant voltage or constant
current for the IPS-4303S.
CH4 Output
Outputs CH4 voltage and current.
Channel
Indicator
COARSE/FINE
FINE
COARSE/FINE
FINE
BEEP
UNLOCK
: Long Push
RECALL /
MEMORY
SAVE
VOLTAGE
Push
Push
CURRENT
1
2
3
4
LOCK
CH1/3
CH2/4
OUTPUT
/INDEP
PARA
/INDEP
SER
DC Power Supply
V
A
V
A
CH4 CH1CH2 CH3
C.V. C.C. PAR. C.V. C.C.
POWER
CH3
0 30V , 3A 0 30V , 3A
CH2 GND
CH1
SLAVE MASTER
SERIES
OUTPUT COM
OUTPUT
PARA
CH4
C.C.C.V.C.C.C.V.
0 5V , 1A 0 5V , 3A
5 10V , 1A
+
+
Indicates which channel the 2 LED
voltmeters/ammeters represent.
