IPS X303 Series Instruc
tion Manual
24
OPERATION
CH1/CH2 Independen
t Mode
Background
/
Connection
CH
1 and C
H2 output
s work independent of each oth
er
.
V
A
V
A
CH4
CH2
GND
CH3
CH1
CH2
LOAD
CH1
LOAD
Output rating
0
to
30V / 0 to 3A
for each channel
Panel operation
1.
M
ake su
re the P
ARA/
INDEP
and SER/INDEP
keys are turned off (the key LEDs are off).
2.
Connect the load to the front p
anel terminals
,
CH
1 +/−,
CH
2 +/−.
