Figure 6. Machine Head Assembling
3). Assembling the System Body
The 4 Omni wheels are locked onto the frame base, and the foot brake can be pressed down
into the locked position for subsequent installation.
Insert three frame pillars into the three square slots of the frame base. Pay careful attention
to the opening direction of the frame pillars, as it is the same as the opening direction of the
frame base. Then screw on the M8 bolts and use a wrench to lock the bolts and fix the
frame pillars.
Place the machine head on the three fixed frame pillars, then determine the orientation and
lock the three M6 screws. Next, fix the machine head and confirm that the entire steel
frame is stable as assembled.
Take out 3 filters and remove their PE protective film. Install the 3 filters: the PP sediment
filter, and 2 CTO filter in order from right to left, and use the housing wrench to tighten the
housing.
Install the water outlet into the outlet of the RO membrane housing. Pay attention to the
interface between pure water and waste water. The water outlet tube is white and blue: the
blue tube runs pure water, and the white tube runs waste water:
