ENGINE MECHANICAL (C22NE, 22LE, 20LE) 6A-51
Reassembly
Reassemble clutch assembly.
Disassembly
Disassemble clutch assembly to flywheel using 5-8840-2634-0
Torque Angle-Method
Clutch assembly to flywheel-17.6Nm/1.8 kgf  m.
Gasket, Oil Pan
Removal
1. Loosen fixing bolts.
2. Remove oil pan from oil pump and cylinder block.
3. Remove oil intake pipe, oil intake pipe bracket, and oil
baffle plate.
Clean
Sealing surfaces.
Installation
1. Apply a bead of Sealing Compound, TB120TC or
eguivalent to joint of oil pump.
2. Install baffle plate, or reuse baffle plate with valcanized
gasket.
Caution
Baffle plates with valcanized gasket can be retrofitted without
difficulty - replace baffle plate with gasket.
3. Install oil intake pipe to oil pump and oil intake pipe
bracket to cylinder block.
4. Install oil pan and new gasket to cylinder block and insert
bolts with Locking Compound 15 10 177 (90 167 347).
Maximum assembly time including torque check is 10
min.
