6A-32 ENGINE MECHANICAL (C22NE, 22LE, 20LE)
Toothed Belt Rear Cover
(Engine with toothed belt tension
roller)
Removal
1. Mark operating direction of toothed belt.
2. Remove toothed belt according to the operation "Toothed
Belt".
3. Remove toothed belt tension roller according to the
operation "Toothed Belt Tension Roller ".
4. Remove fastening bolt while counterholding with 5-8840-
2598-0 (Holding wrench).
5. Remove toothed belt drive gear while counterholding with
5-8840-2598-0 (Holding wrench).
6. Remove camshaft housing cover.
7. Remove camshaft pulley while counterholding at hex
head of camshaft.
8. Remove toothed belt rear cover (arrows) from oil pump
and camshaft housing.
