ENGINE ELECTRICALS
173
Important Operations
3. Rectifier with Brush Holder
4. Stator
When connecting stator coil leads and diode leads
using solder, use long-nose pliers and finish the
work as quickly as possible to prevent the heat from
being transferred to the diodes.
11. Pulley and Fan
Tighten the pulley and fan to the specified torque.
Pulley and Fan Nut Torque kgf·m(lb.ft./N·m)
5.0 – 6.5 (36.2 – 47.7/49.0 – 63.7)
