19. Adjust and fix winch bracket to the
vehicle’s frame, on the left and right
side, using bolts M10x35 and washers
M10.
* Do not tighten yet.
17. Install winch bracket (pos. 2) and
winch on the brackets, using 2 bolts
M12x40, washers M12 and nuts M12 on
the both sides.
* Do not tighten yet.
Repeat step 17.
If so, then remove the winch bracket of
the vehicle, pull the sensor out of the
bracket, bend the bulge side of the
bracket, using pliers inside (marked
green line) and fix the sensor, using tie
wrap, as shown.
18. Check if winch stuck on the center
part of the bracket..
www.rival4x4.com
Date: 30.05.2019
Installation manual 2L.9101.1
< Page 9 of 16 >
Инструкция по установке
INSTALLATION PROCEDURE
