RIGHT SIDE
as viewed in the direction of vehicle motion
1
Masking tape sticking area
Masking tape sticking area
Masking tape sticking area
Template
align area
Template
align area
Attachment #1
TEMPLATE
BUMPER CUT OUT
(RIGHT SIDE)
Cut out line
Connect point №1 and point №2
at the template #2 with cut line
№1
