Isuzu D-Max Installation Manual

21. Use templates, attached in the end
* Stick the template over for more
of this manual, to cut the holes on the
front part of the bumper.
hardness, using scotch tape.
Cut template following dashed line
(attachment 1 and 2), remove area #1,
as shown.
22. Protect the bumper, using masking
tape, as showm.
20. Fix left side of th winch bracket,
using bolts M12x40, insert nuts
M12(pos.9), adjusting washers M12, as
shown.
Make the same actions, on the right
side of the winch bracket.
* Tighten all the joints.
www.rival4x4.com
Date: 30.05.2019
Installation manual 2L.9101.1
< Page 10 of 16 >
Инструкция по установке
INSTALLATION PROCEDURE

Isuzu D-Max Specifications
