Technical Specification
Parameter IT-M7723E
DC current (High
range)
Accuracy ±(0.25%+0.355% F.S.)
DC current (Low
range)
Accuracy ±(0.25%+0.355% F.S.)
Frequency
Range
45～1000Hz
Resolution *5 0.1Hz
Accuracy *2
±0.1%
Power *4
Resolution 100mVA
Accuracy ±(0.5%+0.5% F.S.)
Other
Protection
OTP, OCP, OVP, OPP
Dimension (WxHxD)
Without foot post,
protective cover
215 × 88.2 × 450 mm
With foot post, pro-
tective cover
235.4 × 101.7 × 505.5 mm
Weight
9 KG
*1: Min voltage for THD test is 100Vac.
*2: Min voltage for frequency display accuracy is 100Vac.
*3: Tested with pure resistive load.
*4: This specification is applicable below ≤800Hz.
*5: The applicable range of frequency resolution is 45~99.9Hz.
Copyright © Itech Electronic Co., Ltd.
131
