Appendix
Model
Specifica-
tion
Length Description
IT-E32410-OO 240A 1m
A pair of red and black test ca-
bles with round terminals at both
ends
IT-E32420-OO 240A 2m
A pair of red and black test ca-
bles with round terminals at both
ends
IT-E33620-OO 360A 2m
A pair of red and black test ca-
bles with round terminals at both
ends
For maximum current of AWG copper wire, refer to table below.
AWG 8 10 12 14 16 18 20 22 24 26 28
The
Maxi-
mum
Current
Value (A)
60 40 30 20 13 10 7 5 3.5 2.5 1.7
• AWG (American Wire Gage), it means X wire (marked on the wire). The table
above lists current capacity of single wire at working temperature of 30°C. For
reference only.
• Along with temperature, you must also consider voltage drop when selecting
wire sizes.
Although the instrument will compensate for the voltage in the wires, it is recom-
mended to minimize the voltage drop as much as possible to prevent excessive
power consumption from the instrument and poor dynamic response to load
changes. Larger diameter wire sizes will help minimize wire voltage drops.
Twisting or bundling wires will help reduce transient voltage drops.
A.2 Built -in Waveforms
The ITM7700 series power supply is built in with 30 waveforms up to 40 times of
harmonic distortion. The table below lists each time of harmonic component of
each harmonic wave. In the table below, N means the number of harmonic
waves, and % means the percentage of this time of harmonic wave in the base
Copyright © Itech Electronic Co., Ltd.
133
