Technical Specification
7 Technical Specification
This chapter will introduce the rated voltage, current, power and many other
main parameters of IT-M7700 series power source.
♦ IT-M7721
♦ IT-M7721L
♦ IT-M7722
♦ IT-M7722D
♦ IT-M7722E
♦ IT-M7722L
♦ IT-M7723
♦ IT-M7723D
♦ IT-M7723E
7.1 IT-M7721
Parameter IT-M7721
AC Input
Voltage
100～240Vac
Phase
Single-phase
Frequency
47～63Hz
Max.current 4.3A
Power factor
0.99 (Typical)
AC Output
Max. output power
300VA
Max. output voltage
300V
Output phase Single-phase
Current range(rms)
3A
Current range(peak)
9A
Output frequency range
45～1000Hz
Phase angle degree range
0～359.9°
THD*1*3
≤0.3% at f=45～100Hz
≤1% at f=101～800Hz
≤ (0.15%f-0.2)% at f=801～1000Hz
Copyright © Itech Electronic Co., Ltd.
111
