Set the instruments to series oper-
ation mode.
3 Phase
Set the instruments to 3-phase op-
eration mode.
Table 1–4 IT-M7721L/IT-M7722L menu
Config Configuration menu
AC + DC
Set the AC + DC output mode.
Off
Turn off AC + DC output mode.
On
Turn on AC + DC output mode.
On Phase
Set the starting phase angle of the waveform. (only displayed
under the AC Mode)
Off Phase
Set the ending phase angle of the waveform. (only displayed
under the AC Mode)
V-Rise Time
Set the voltage rising time. (only displayed under the DC
Mode)
Table 1–5 IT-M7723 menu
Config Configuration menu
V Range Set the voltage measurement range.
High High range
Low
Low range
AC + DC
Set the AC + DC output mode.
Off
Turn off AC + DC output mode.
On
Turn on AC + DC output mode.
On Phase
Set the starting phase angle of the waveform. (only displayed
under the AC Mode)
Off Phase
Set the ending phase angle of the waveform. (only displayed
under the AC Mode)
V-Rise Time
Set the voltage rising time. (only displayed under the DC
Mode)
Wave
Set the output waveform type. (only displayed under the AC
Mode)
Sine Sinusoidal
Square Square
Triangle Triangle
