Power Supply Function
maximum energy that is generated by the PV array. SAS function menu is as
follows:
SAS SAS function menu
Run Indicates to enter the SAS function mode and wait for the
trigger to run the currently selected PV curve file.
Static Static PV curve setting.
Curve Open or edit a fixed format PV curve.
Open Select a fixed format PV curve.
Recall
Inner
Sas File
Set the name of the PV curve
file and recall the PV file
stored inside the instrument.
Edit Edit a fixed format PV curve.
Pmp Set the maximum power.
Vmp Set the maximum power
voltage.
Formula Regulatory settings. The
choice of solar panel materi-
als under different regulations
is different.
SANDIA
• TF: Thin-Film
• SCMC: Stand-
ard Crystalline
or Multi-
crystalline
• HEC: High-effi-
ciency
Crystalline
E-
N50530
• TF: Thin-Film
• cSi
Save To Set the saved file name. Pa-
rameter setting ranges from 1
to 100
User-
de-
fined
User-definable PV curves
Copyright © Itech Electronic Co., Ltd.
142
