Power Supply Function
Inner
Resistance
Simulates the internal
resistance of a cell
battery.
Capacity
Simulates the capacity
of a cell battery.
Parallel
Set the number of paral-
lel connected batteries.
Serial
Set the number of bat-
teries in series.
I+
Positive current limit val-
ue, which simulates the
maximum discharge cur-
rent of the battery pack.
I-
Negative current limit
value, which simulates
the maximum charge
current of the battery
pack.
Save To
Group
Set the save address of
the user-defined battery
emulation file.
Curve
Select the battery simulation curve file for
testing.
Run
Run the currently selected battery sim-
ulation curve file.
Initial Value
Set the initial state of
charge (SOC) of the bat-
tery. 0~100% corre-
sponds to the voltage
range from no-load volt-
age to full-load voltage.
Open
Open or select a battery simulation
curve file.
USB
Select the battery simu-
lation curve file stored in
the USB flash disk.
